제노스 모든 제품은 ISO 국제표준규격 기반의
체계적이고 철처한 품질관리시스템에 따라 제조됩니다.
| Nominal Pressure | 7ATM (1.00mm~1.50mm) |
Max. Guide wire OD | 0.014"(0.36mm) |
| 8ATM (1.00mm~1.50mm) |
Catheter type | Rapid Exchange | |
| Rate Burst Pressure | 15ATM (1.00mm~1.50mm) | Proximal Shaft | 2.0Fr(0.68mm) |
| 16ATM (2.00mm~3.50mm) | Distal shaft | 2.5Fr(0.82mm)/2.8Fr(0.92mm) | |
| 14ATM (3.75mm~4.00mm) | Lesion entry profile | 0.017"(0.43mm) | |
| Ballon material | Semi-Compliant | Usable length | 1450mm |
| Min. Guiding catherter ID | 5Fr(1.42mm),0.056" | Shelf life | 3years from steilization date |
| Balloon Diamiter (mm) |
Balloon length (mm) | |||||||||
| 5 | 10 | 12 | 15 | 18 | 20 | 25 | 30 | 35 | 40 | |
| 1.00 | GBC-05-100 | GBC-10-100 | GBC-12-100 | GBC-15-100 | - | - | - | - | - | - |
| 1.10 | - | GBC-10-110 | - | - | - | - | - | - | - | - |
| 1.25 | - | GBC-10-125 | GBC-12-125 | GBC-15-125 | - | GBC-20-125 | - | - | - | - |
| 1.50 | - | GBC-10-150 | GBC-12-150 | GBC-15-150 | - | GBC-20-150 | - | - | - | - |
| 2.00 | - | GBC-10-200 | GBC-12-200 | GBC-15-200 | GBC-18-200 | GBC-20-200 | GBC-25-200 | GBC-30-200 | GBC-35-200 | GBC-40-200 |
| 2.50 | - | GBC-10-250 | GBC-12-250 | GBC-15-250 | GBC-18-250 | GBC-20-250 | GBC-25-250 | GBC-30-250 | GBC-35-250 | GBC-40-250 |
| 2.75 | - | GBC-10-275 | GBC-12-275 | GBC-15-275 | GBC-18-275 | GBC-20-275 | GBC-25-275 | GBC-30-275 | GBC-35-275 | GBC-40-275 |
| 3.00 | - | GBC-10-300 | GBC-12-300 | GBC-15-300 | GBC-18-300 | GBC-20-300 | GBC-25-300 | GBC-30-300 | GBC-35-300 | GBC-40-300 | 3.25 | - | GBC-10-325 | GBC-12-325 | GBC-15-325 | GBC-18-325 | GBC-20-325 | GBC-25-325 | GBC-30-325 | GBC-35-325 | GBC-40-325 |
| 3.50 | - | GBC-10-350 | GBC-12-350 | GBC-15-350 | GBC-18-350 | GBC-20-350 | GBC-25-350 | GBC-30-350 | GBC-35-350 | GBC-40-350 |
| 3.75 | - | GBC-10-375 | GBC-12-375 | GBC-15-375 | GBC-18-375 | GBC-20-375 | GBC-25-375 | GBC-30-375 | GBC-35-375 | GBC-40-375 |
| 4.00 | - | GBC-10-400 | GBC-12-400 | GBC-15-400 | GBC-18-400 | GBC-20-400 | GBC-25-400 | GBC-30-400 | GBC-35-400 | GBC-40-400 |
| 4.50 | - | GBC-10-450 | GBC-12-450 | - | - | - | - | - | - | - |
| 5.00 | - | GBC-10-500 | GBC-12-500 | - | - | - | - | - | - | - |
